6000Liters to 8000Liters Fire Fighting Trucks |
||
|
Chassis Model /Manufacturer |
ISUZU |
|
|
cab |
With sleeper |
|
|
Overall Dimension（ L×W×H） |
8600*2500*3000mm |
|
|
Kerb Weight |
9420Kgs |
|
|
front overhang/rear overhang |
1335/2665 |
|
|
Engine |
Model/Rated Power |
4HK1-TCG40 140KW/190HP 4 cylinder |
|
|
Displacement |
5193CC |
|
|
Emission Standard |
Euro 4 |
|
|
manufacturer |
ISUZU engine |
|
Type & Size of Tyre |
10.00R20 |
|
|
driving type |
4×2 |
|
|
Wheel Base |
4500 mm |
|
|
Max Speed |
90 Km/h |
|
|
Capacity of tank body |
6000Liters to 8000Liters |
|
|
Liquid tanker |
Volume: total 6000L, (among, water: 5000L; FOAM:1000 L) Material: high quality carbon steel plate, anti-rust treatment inside. Structure: welding, there is baffle plate inner. Equipment: 1 manholes, with speediness lock and turn on equipment. 1 overflow mechanisms 1 drainage exits |
|
|
Fire fighting pump and pipeline system |
Model of Fire fighting pump: CB10/40 Pressure: 1.0Mpa Flux: 40L/s Suction depth: ≥7m Suction time: ≤35s Installing type: central or rear |
|
|
Fire fighting monitor |
Model: PP32 Range: water≥50m foam≥45m Pressure: 1.0Mpa. |
|
|
PTO |
sandwich PTO, splashing-type lubricate, can put out fire when driving. |
|
|
ISUZU MLD 6 forwards + 1 reverse, with air condition, power steering, Electrical glass, USB System Brake: air Brake Front Axle( Loading capacity): 6.3T Rear Axle( Loading Capacity): 13T Battery: 12V*2 115Ah*2 |
||
